Pressure Relief Valve Debugging Procedure
Debugging the pressure relief valve (PRV) of a steel tank is a critical safety procedure to ensure it activates correctly under overpressure conditions.
Preparation
Required Tools
- Calibrated pressure gauge (within last 12 months)
- Wrench set
- Portable air compressor or hydraulic pump
- Personal protective equipment (gloves, goggles, steel-toe boots)
Ensure the tank is depressurized and isolated from the system to prevent accidental pressure buildup during debugging.
Visual Inspection
Check for:
- Corrosion or cracks in the valve body
- Debris in the inlet/outlet ports
- Proper set pressure marking (e.g., 100 psi for a 150 psi tank)
Clean the valve with a soft brush and solvent if needed, ensuring no particles block the mechanism.
Pressure Testing
Test Setup
- Connect pressure source to tank's inlet
- Attach gauge to test port near PRV
- Gradually increase pressure while monitoring
The valve should open at its preset value. If activation is early/late, adjust spring tension using the valve's adjustment screw (consult manufacturer's manual for torque limits).
Leak Testing
After proper activation is confirmed, reduce pressure slowly to check for tight closure:
Leak Detection
- Apply soapy water solution to outlet
- Bubbles indicate faulty seal
- Replace valve seat or diaphragm if leaking
Documentation
Record These Details
- Set pressure
- Actual activation pressure
- Adjustments made
- Next scheduled test date
Affix a calibration sticker with the date (typical interval: 6-12 months).
Safety Warning
Never bypass or disable the PRV - it is the primary safety barrier against tank overpressure and potential explosions.
